CCR Liberty - Heavy

The Divesoft Liberty CCR is a cutting-edge electronic closed-circuit rebreather (eCCR) that has redefined technical diving. Its modular design, user-friendly interface, and exceptional performance have made it a favorite among experienced divers.

This particular configuration, the Liberty Heavy, is built for demanding dives and offers a DIR (Doing It Right) style setup with a robust tubular stand and the flexibility to use any size of onboard cylinders.

Key Features:

The Liberty Heavy provides unparalleled customization. Divers can choose between a traditional CCR setup with 3L cylinders or a DIR style setup with onboard bailout.  It features a removable backplate for easy adjustments and a wire stand that allows for convenient clipping of cylinders and accessories.  The unit can accommodate up to 4 onboard cylinders, providing ample gas supply for extended dives.

Included Components:

• Liberty Heavy frame with exchangeable cylinder holders
• Removable wire stand
• Divesoft CCR Wing
• Backplate
• 1st stage regulators with Divesoft Technical connections, hoses, and SPGs
• Single Hose Adapter

Not Included:

• Cylinders
• Valves
• 7ft long hose
• 2nd stage regulator(s) (for DIR configuration)

Advanced Technology:

The Liberty CCR boasts a range of advanced features, including redundant Shearwater electronics, a dual-use scrubber canister design, and a variety of safety features like closed-circuit detection and a built-in gas analyzer.  It also offers Bluetooth connectivity for easy data logging and firmware updates.

Experience the pinnacle of technical diving with the Divesoft Liberty CCR.

Head:

• 2 control units in individually sealed compartments
• All components inside the head are sealed
• Wet connectors for displays
• 4 O2 cells (2 for each control unit)
• O2 calibration with supplied jig
• 4 pressure sensors (2 for each part of the unit)
• 2 optional helium sensors
• 2 magnetic solenoid valves
• 2 Li-Ion batteries (USB rechargeable)
• 2 handsets with vibration alarms, thermometers, inclinometers, accelerometers, and light sensors
• 4 displays (2 handsets, HUD/ODA, and buddy display)
• HUD option with rotating shade and color-blind mode
• ODA option with built-in compass and buddy display

Other:

• Air integration with pressure sensors
• Closed cylinder detection
• Built-in gas analyzer
• Bluetooth connection
• Built-in pre-dive check
• Pressure tests done in 1 minute
• ADV (Diaphragm Automatic Diluent Valve)
• Cordura counterlungs with OPV
• Manual addition valves (MAVs)
• Flood tolerance
• Choice of BOV/DSV
• Heavy wing (20l/44 lbs)
• Choice of scrubber size (Standard or XL)
• Backplate (3mm stainless steel)
• Cylinder configuration (Traditional or DIR)
• Quick release system

Dimensions (LP50s Configuration):

• Height: 720 mm (28.35 in)
• Width: 445 mm (17.52 in)
• Depth: 240 mm (9.45 in)

Dimensions (2x3L Configuration):

• Height: 680 mm (26.77 in)
• Width: 365 mm (14.37 in)
• Depth: 230 mm (9.06 in)

Weight (Empty, no cylinders):

• 2x3L: 21.3 kg (47 lb) + backplate (SS BP - 2.90 kg (6.4 lb))
• 2xLP50: 22.5 kg (49.6 lb) + backplate (SS BP - 2.90 kg (6.4 lb))

Scrubber:

• Standard: 2.50 kg (5.51 lb) – 4-6 hours of runtime
• X-Large: 3.30 kg (7.28 lb) – 5-8 hours of runtime
